‍Model

CESS-HY-40K

MPPT voltage range / rated input voltage

200V to 850V / 620V

No. of MPPT / No. of DC Inputs per MPPT

4 / 2

Max. PV input current

30Ax4

Battery voltage range

135V to 750V

Rated grid side output power

40kW

Max. grid side output apparent power

44kVA

Max. grid side input apparent power

48kVA

Rated Back-up side output power

40kW

Max. switch time

<20ms

Ingree protection degree

IP65

Certificates

EN 61000/IEC 62109/EN 50549/VDE-AR-N-4105

‍
